waterfall hardwood and vinyl flooring tile tower display-wl606

DISPLAY Product Overview

The DISPLAY frame starts as cold-rolled steel tube, cut and welded on CNC jigs to maintain consistent slot spacing across every unit. No shims, no field adjustments needed.

We pre-drill and tap every threaded insert on the DISPLAY before finishing, so the powder coat never fills the threads. Your assembly bolts go in clean every time.

Tile samples look their best when customers can see the full face without bending or reaching. The DISPLAY angles every panel slightly toward the viewer, reducing glare from overhead showroom lighting.

We manufacture the DISPLAY in our Xiamen facility where we control every step from steel procurement to final assembly. No subcontractors, no quality gaps.

Key Features

• EPDM rubber contact pads at all sample touch points — rated for permanent indoor use
• Push-pull rail mechanism rated at 50kg per rail — keeps heavy slabs gliding smoothly after years of daily use
• Slot-to-slot spacing adjustable from 15mm to 45mm without disassembly
• Load-rated at 75kg per shelf — holds even the thickest 1200×1200mm porcelain slabs
• Stainless steel ball-bearing sliders with dampened stops — panels glide, then lock into viewing position without slamming
• CNC-laser-cut slot brackets with ±0.5mm tolerance — every panel sits at exactly the same angle
• Tool-free slot adjustment — lift the bracket, slide to desired position, release to lock
• Integrated floor anchors included — zero tip risk even with all panels pulled out simultaneously

Why Buy Direct from Tsianfan

• Factory tours welcome in person or via live video — see your order on the production line
• Every rack completes a 72-hour salt-spray corrosion test before it ships
• 11 years manufacturing display systems exclusively for the building materials industry
• We ship to 50+ countries with correct export documentation on every shipment
• Custom engineering proposals delivered within 3 business days of receiving your requirements

Where This Display Rack Fits

Factory sample rooms for export-oriented manufacturers

Ordering & Customization

Every order starts with your requirements — dimensions, color, capacity, branding. Contact our sales team at WhatsApp: +86 13365904989 or email: [email protected]. We prepare a detailed quotation with production timeline, typically within 24 hours. For custom sizes, include a simple sketch or reference dimensions — our engineering team handles the rest.
