floor tiles display stone tile display stand-SRT918

STAND Product Overview

We pre-drill and tap every threaded insert on the STAND before finishing, so the powder coat never fills the threads. Your assembly bolts go in clean every time.

If your sales team spends more time fetching samples from the back than talking to customers, the STAND puts your entire collection at their fingertips — literally within arm’s reach of the consultation desk.

The slot liners on the STAND are made from EPDM rubber, the same material used in automotive weather seals. They do not harden, crack, or leave marks on your tile edges.

Tile samples look their best when customers can see the full face without bending or reaching. The STAND angles every panel slightly toward the viewer, reducing glare from overhead showroom lighting.

Key Features

• Stainless steel ball-bearing sliders with dampened stops — panels glide, then lock into viewing position without slamming
• Tool-free slot adjustment — lift the bracket, slide to desired position, release to lock
• Push-pull rail mechanism rated at 50kg per rail — keeps heavy slabs gliding smoothly after years of daily use
• Integrated floor anchors included — zero tip risk even with all panels pulled out simultaneously
• Pre-assembled slider carriages — no loose ball bearings to deal with during setup
• Cross-braced rear panel eliminates side-to-side sway when panels are being browsed
• Load-rated at 75kg per shelf — holds even the thickest 1200×1200mm porcelain slabs
• Modular end-frames bolt together in any combination — start with 8 slots, expand as your line grows

Why Buy Direct from Tsianfan

• Engineering support included at no charge — send us your floor plan for an optimized layout proposal
• Every rack completes a 72-hour salt-spray corrosion test before it ships
• Custom engineering proposals delivered within 3 business days of receiving your requirements
• Factory tours welcome in person or via live video — see your order on the production line
• 11 years manufacturing display systems exclusively for the building materials industry

Where This Display Rack Fits

Hotel and hospitality project material libraries

Ordering & Customization

Every order starts with your requirements — dimensions, color, capacity, branding. Contact our sales team at WhatsApp: +86 13365904989 or email: [email protected]. We prepare a detailed quotation with production timeline, typically within 24 hours. For custom sizes, include a simple sketch or reference dimensions — our engineering team handles the rest.

Common Questions
